Migrating Ghost Blog from AKS to LKE

My ghost blog (ccrowell.com) has been running on AKS. If you are cost concious, I wouldn't recommend doing this, but I had some Azure credits and was feeling adventurous. Also, I thought it would be good practice for running "real" workloads on. The pieces to this puzzle were:

• Creating a custom ghost image and pushing to a container registry (I chose ACR)
• Installing cert-manager and nginx-ingress in my cluster
• DNS hosting of some sort (not as important as the rest)
• A deployment, a ClusterIP service, a tls secret, and an ingress resource.
• A persistent volume claim using the default storage class

Backing up the Ghost Data from AKS

My ghost data was inside a PersistentVolume in Kubernetes, but the underlying storage was an Azure file share. To back up the data, I had to mount the azure file share locally and copy the data to my machine locally.

# find the name of the secret starting with 'azure-storage-account'
kubectl -n ghost get secret

# get the storage account name
kubectl -n ghost get secret azure-storage-account-* -o jsonpath='{.data.azurestorageaccountname}' | base64 --decode

# get the storage account key
kubectl -n ghost get secret azure-storage-account-* -o jsonpath='{.data.azurestorageaccountkey}' | base64 --decode

# get the name of the pvc used with your ghost deployment (mine was just called 'ghost-pvc')
kubectl -n ghost get pvc

# get the azure fileshare name (you can also get this from azure-cli)
kubectl -n ghost get pvc <pvc-name> -o jsonpath="{.spec.volumeName}"

# install cifs-utils, and make a backup directory
sudo mkdir -p ~/ghost-backup

# mount the azure file share
sudo mount -t cifs //<storage-account-name>.file.core.windows.net/<file-share-name> ~/ghost-backup -o vers=3.0,username=<storage-account-name>,password=<storage-account-key>,dir_mode=0777,file_mode=0777

# copy the ghost data to the dir I just created
cp -r ~/ghost-backup ~/ghost-backup-local

# unmount the azure file share
sudo umount ~/ghost-backup

Backing up the Ghost Database

The next step was to back of the sqlite database. Since I was using sqlite instead of SQL, the backup process was just a matter of backing up the sqlite file directly. This file is commonly named 'ghost.db'.

# find the database name
kubectl -n ghost exec -it <ghost-pod-name> -- cat /var/lib/ghost/config.production.json

# copy the 'ghost.db' file to your local machine using kubectl cp
kubectl cp <ghost-pod-name>:/var/lib/ghost/content/data/ghost.db ./ghost.db -n ghost

# verify the file was copied successfully
ls -lh ghost.db

Backing up the TLS secret

The TLS secret is used with cert-manger for HTTPS communication to your domain (Let's Encrypt certificate requested from cert-manager). Cert-manager also renews the certificate before it expires. We can generate a new certificate when we create the new cluster, but I decided to transfer the SSL certificates directly.

# get the tls secrets in your AKS cluster
kubectl -n ghost get secrets

# backup the TLS secret from AKS
kubectl -n ghost get secret my-tls -o yaml > my-tls.yaml

Creating an LKE cluster

1. Log into Linode Cloud Manager.
2. Navigate to Kubernetes > Create a Cluster.
3. Choose a Kubernetes Version and Region.
4. Select the number and type of nodes.
5. Click Create Cluster and download your kubeconfig file.

export KUBECONFIG=~/path/to/linode-kubeconfig

kubectl get nodes

Set Up Persistent Storage in LKS

Since Linode does not have Azure File Shares, you need to use Linode Block Storage:

1. Create a Persistent Volume Claim (PVC):

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: ghost-pvc
  namespace: ghost
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 10Gi
  storageClassName: linode-block-storage-retain

kubectl apply -f ghost-pvc.yaml

Deploy Ghost on LKS

1. Update Your Ghost Deployment YAML to Use Linode Block Storage:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: ghost
  namespace: ghost
spec:
  replicas: 1
  selector:
    matchLabels:
      app: ghost
  template:
    metadata:
      labels:
        app: ghost
    spec:
      containers:
        - name: ghost
          image: cmcrowell.azurecr.io/cmcrowell-ghost:v5.6
          imagePullPolicy: IfNotPresent
          env:
            - name: url
              value: https://cmcrowell.com
          ports:
            - containerPort: 2368
              name: http
              protocol: TCP
          resources:
            limits:
              cpu: "1"
              memory: 256Mi
            requests:
              cpu: 100m
              memory: 64Mi
          volumeMounts:
            - name: ghost-content
              mountPath: /var/lib/ghost/content
      volumes:
        - name: ghost-content
          persistentVolumeClaim:
            claimName: ghost-pvc

1. Apply the Deployment:

kubectl apply -f ghost-deploy.yaml

Restore Ghost Data to LKS

1. Transfer Data to Linode Block Storage:

• If using scp to move backup data:

scp -r ghost-backup-local <linode-server>:/mnt/ghost-data

• Or use kubectl cp to copy data into the new pod:

k -n ghost cp ghost-backup-local ghost-799fc9988-2bzsz:/var/lib/ghost/content

1. Restore the Database:

# Copy the `ghost.db` file to the new Ghost pod
kubectl -n ghost cp ghost.db ghost-799fc9988-2bzsz:/var/lib/ghost/content/data/ghost.db

# Ensure proper file permissions inside the pod
kubectl exec -it ghost-799fc9988-2bzsz -n ghost -- chmod 644 /var/lib/ghost/content/data/ghost.db

Update DNS and Test the Migration

1. Expose the Ghost Service via ClusterIP

apiVersion: v1
kind: Service
metadata:
  name: ghost
  namespace: ghost
spec:
  type: ClusterIP
  ports:
    - port: 80
      protocol: TCP
      targetPort: 2368
  selector:
    app: ghost

kubectl apply -f ghost-service.yaml

1. Update Your Domain’s DNS

• Point your domain (e.g., blog.example.com) to the new LKS LoadBalancer IP.

1. Verify the Blog is Running

kubectl get pods -n <ghost-namespace>kubectl logs -f <ghost-pod-name> -n <ghost-namespace>

Install NGINX Ingress Controller in LKS

Linode Kubernetes Service (LKS) does not come with an Ingress Controller by default, so we need to install it.

Option 1: Install via Helm

1. Add the Helm repo for NGINX Ingress:

helm repo add ingress-nginx <https://kubernetes.github.io/ingress-nginx>
helm repo update

1. Install the NGINX Ingress Controller in the ghost namespace:

helm install nginx-ingress ingress-nginx/ingress-nginx --namespace ghost --set controller.service.type=LoadBalancer

you will get the following output:

$ helm install nginx-ingress ingress-nginx/ingress-nginx --namespace ghost --set controller.service.type=LoadBalancer
NAME: nginx-ingress
LAST DEPLOYED: Mon Feb 24 16:08:19 2025
NAMESPACE: ghost
STATUS: deployed
REVISION: 1
TEST SUITE: None
NOTES:The ingress-nginx controller has been installed.
It may take a few minutes for the load balancer IP to be available.
You can watch the status by running 'kubectl get service --namespace ghost nginx-ingress-ingress-nginx-controller --output wide --watch'

1. An example Ingress that makes use of the controller:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: example
  namespace: foo
spec:
  ingressClassName: nginx
  rules:
    - host: www.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: exampleService
                port:
                  number: 80
  tls:
    - hosts:
        - www.example.com
      secretName: example-tls

1. verify the installation:

kubectl get pods -n ghost
kubectl get svc -n ghost

1. Get the IP of the LoadBalancer:

kubectl get svc -n ghost

Use EXTERNAL-IP (e.g. 45.79.240.133) to update your DNS (cmcrowell.com).

Deploy Cert-Manager in LKS

Cert-Manager is used to manage SSL/TLS certificates automatically.

Install Cert-Manager using Helm

helm repo add jetstack <https://charts.jetstack.io>
helm repo update
helm install cert-manager jetstack/cert-manager --namespace cert-manager --create-namespace --set installCRDs=true

you will get the following ouptput:

$ helm install cert-manager jetstack/cert-manager --namespace cert-manager --create-namespace --set installCRDs=true
NAME: cert-manager
LAST DEPLOYED: Mon Feb 24 16:11:36 2025
NAMESPACE: cert-manager
STATUS: deployed
REVISION: 1
TEST SUITE: None
NOTES:⚠️  WARNING: `installCRDs` is deprecated, use `crds.enabled` instead.
cert-manager v1.17.1 has been deployed successfully!
In order to begin issuing certificates, you will need to set up a ClusterIssuer
or Issuer resource (for example, by creating a 'letsencrypt-staging' issuer).More information on the different types of issuers and how to configure them
can be found in our documentation:
<https://cert-manager.io/docs/configuration/For> information on how to configure cert-manager to automatically provision
Certificates for Ingress resources, take a look at the `ingress-shim`documentation:<https://cert-manager.io/docs/usage/ingress/>

verify:

k -n cert-manager get po

Backup and Restore Your TLS Secret

Your TLS secret cmc-tls stores SSL certificates. We’ll transfer it from AKS to LKS.

backup the TLS secret from AKS:

kubectl get secret cmc-tls -n ghost -o yaml > cmc-tls.yaml

Restore the TLS Secret to LKS

Modify the cmc-tls.yaml file:

• Remove metadata.resourceVersion
• Remove metadata.uid

Then apply it in LKS:

kubectl apply -f cmc-tls.yaml -n ghost
# verifyk -n ghost get secret

4️⃣ Migrate Your Ingress Configuration

Now, we’ll recreate the Ingress resource in LKS.

Backup Ingress from AKS

kubectl get ingress ingress-ghost -n ghost -o yaml > ingress-ghost.yaml

Modify ingress-ghost.yaml

1. Remove metadata.resourceVersion and metadata.uid
2. Ensure ingress.class is still nginx
3. Update cmcrowell.com DNS record to point to your LKS LoadBalancer EXTERNAL-IP
4. Ensure the tls.secretName is set to cmc-tls

Apply the Ingress to LKS

kubectl apply -f ingress-ghost.yaml -n ghost
# verifyk -n ghost get ing

5️⃣ Test Your Migration

1. Check if NGINX Ingress Controller is Running

k -n ghost get po

Verify Cert-Manager Issued the TLS Certificate

k -n ghost describe certificate cmc-tls

Test Your Website

• Visit https://cmcrowell.com in a browser.
